Silicon Wafer & Other Substrate Specials
Partial Silicon Wafer Cassettes
We have a large inventory of high-quality partial Silicon Wafer cassettes that you can buy as few as one! Please ask for the list.
Simox SOI Sale 150mm and 200mm available.
200mm SIMOX SOI Wafers in StockNew Sale on Simox SOI Wafers! | ||||
| Device Layer (nm) | Box Layer (nm) | Handle Layer (um) | TTV (um) | Qty in Stock |
| 55 | 145 | 725+/-15 | <1 | 184 |
| 70 | 145 | 725+/-15 | <1 | 253 |
| 70 | 2000 | 725+/-15 | <1 | 1756 |
| 75 | 250 | 725+/-15 | <1 | 18 |
| 80 | 1000 | 725+/-15 | <1 | 374 |
| 88 | 200 | 725+/-15 | <1 | 23 |
| 145 | 1000 | 725+/-15 | <1 | 9166 |
| 160 | 400 | 725+/-15 | <1 | 24 |
| 300 | 300 | 725+/-15 | <1 | 43 |
| 400 | 150 | 725+/-15 | <1 | 21 |
| 700 | 2000 | 725+/-15 | <1 | 22 |
| 1250 | 145 | 725+/-15 | <1 | 353 |
| 1250 | 400 | 725+/-15 | <1 | 19 |
| 2100 | 400 | 725+/-15 | <1 | 16 |
| 3500 | 400 | 725+/-15 | <1 | 46 |
| 3000 | 300 | 725+/-15 | <1 | 4414 |
What SIMOX SOI Wafer Specs Are Used To Fabricate Devices?
We use SOI for our device work – usually as 10 mm x 10 mm or 15 mm x 15 mm chips - so you'll appreciate that one-off 200 mm wafer should keep us well supplied for some time. To make our devices (single electron transistors) we have to have a highly n-doped device layer - a virtual conductor – but if required we can use a spin-on dopant to generate this ourselves. I dont think any of your material has the necessary doping level – but thats no problem Your SIMOX SOI Part 2551 might well furnish our need. I am unclear as to the formalities required to purchase from one wafer from you. Are you able to send a quote so that I can place an order and will that include custom clearance, packing and and postage.
Reference #225661 for pricing or buy online.
------------------
Silicon Carbide Wafers (Made in the USA)
SK Siltron CSS™ 4H-1460 n+ SiC TEST GRADE DR WAFER | |||
GMID | Quantity Range | Price per unit | |
4119951 | Min | Max | |
25 | 100 | $Contact Us | |
SK Siltron CSS™ 4H-1460 n+ SiC PRIME GRADE WAFER | |||
GMID | Quantity Range | Price per unit | |
4140052 | Min | Max | |
25 | 100 | $Contact Us | |
Ultra-Thin Silicon Wafers
We plan to do PVD coating on this wafer. Our coating system has a
4” diameter mounting surface. The wafer must be mounted on this surface so it must not fracture when bent to a radius of 50.8 mm. We think a polished high quality crystal of 50 micron thickness should have a critical bending radius of about 37 mm. We have a reel-to-reel coating system that can do several square meters of coating per day. We think this system might be great for coating of Solar Panels and other high volume needs. I have attached a publication reporting bending studies on 50 um silicon.
Reference #265057 for pricing.
2 micron thin available
25.4mm Silicon Wafers
University researchers and industry scientists use 1 inch
silicon wafers for their projects because they are easy to work with and inexpensive equipment is readily available. Small diameter wafers are a low-cost alternative to larger diameter wafers which cost more and require more expensive equipment.
Typical researcher quote request.
"Please, send us quotation for ten zero-diffraction plates for powder XRD with following specs: Diameter 32 mm Thickness approx 2 mm Single Side Polished w/o cavity Example - Off Ori 9° of (001) or other Thank you in advance."
Reference #268940 for specs and pricing.
Undoped, Boron, Arsenic, Antimony Doped in Stock
------------------------------------------
50.8mm Silicon Wafers
(100) (111) (110) & Other Oris
I'm wondering if you have silicon wafers that are polished
on both sides.
I need only one or two wafers, ~2 inch diameter, 0.5-1 mm thick. I use them as dichroic mirrors (transmit IR and reflect visible light). Most importantly they have to be polished on both sides.
Reference #249131 for specs and pricing.
-------------------------------------------
UniversityWafer, Inc. is mentioned in over 20,000 academic research papers. Below is a typical interaction.
Hello! We are looking for a product that was referenced in
some publications : “Silicon wafers (3-inch diameter, Type-P, 1S polished; University Wafer, cat. no. S3P01SP” (referenced by doi:10.1038/nprot.2013.046) However I cannot find that product on your web site. Do you have any suggestions of which product might work for the same applications? I was thinking that # 978 would probably work (7.6 cm, single side polished, type p) but was not sure. Can you maybe confirm?
Single and Double Side Polished
Material, life sciences and nanomedicine researchers have used 76.2mm Silicon Wafer Item #1318 to measure the dimensions of nanoscale objects.
https://www.universitywafer.com/silicon-wafer.html
Please reference #260858 for specs and pricing.
